Tag Archives: leather paring knives

August Eickhoff French Style Paring Knives

A pair of August Eickhoff french style paring knives, made in New York, 19th century.

A side benefit of my regrinding and knife sharpening service is that I get to see some interesting antique knives. These August Eickhoff knives are beautifully made, have a wonderful balance, a lovely patina, and given the amount of distal taper (both on the blade and the tang) must have been forged. Eickhoff also made round knives (aka. head knives) for leatherworkers which occasionally show up for sale today. In the late 19th century, Eickhoff was located at 381 Broome St, NYC, making scissors, woodworking tools, and resharpening knives. He served on the NY Board of Education, and advertised his wares in a Teachers College Educational Monograph. It may be time to make a few reproduction Eickhoff knives.

New Tool For Sale! The M2 Hybrid Paring Knife

Traditionally, leather paring knives either have round or straight cutting edges.  I discuss the advantages and disadvantages of each in this post. I usually use an English style straight blade, but became tired of the fact it could only be used for edge paring. Partially inspired by the rounded corners of a spokeshave blade, I made a couple of other modifications to a standard M2 English style knife so that it can be used for more than edge paring.

A slightly curved cutting edge on essentially an English style knife allows it to scoop out leather, necessary for the spine area, headcaps, and decorative work. The blade is oriented at a 45 degree angle, like an English knife, so right and left handers need to purchase different knives. The corners of the knife are rounded so that the tip or heal will not cut through the skin while performing this scooping action. The tiny secondary bevel allows quick resharpening.

This knife can be used for all types of paring necessary in bookbinding: edge paring, reducing spine and caps, paring deep into a skin (similar to a spokeshave’s action) and even for overall scraping, if you are into that.

M2 Hybrid Knife. Around 8 – 9 inches long, and 1 inch wide. Since the grind marks on the primary bevel go along the length of the blade, the primary bevel is not apparent when looking at the top of the knife. The exact curve of the cutting edge varies a bit from knife to knife.

A lower angle primary bevel cuts down on the amount of time it takes to resharpen the blade, since there is less metal to remove. The 13 degree cutting edge is only a millimeter or two. The disadvantage is that there is not a large enough bevel that you can feel when you put your knife on the sharpening substrate; you have to trust your hands and the angle you are holding it at. This is quite similar to sharpening a kitchen knife by hand. Another advantage of the small secondary bevel is that it can be stropped back into shape very quickly, again because not much metal has to be removed. This is a perfect blade for sub-micron stropping. M2 steel seems easier to strop than A2, for some reason.

Cross section of primary and secondary bevels.

The slightly curved blade creates more opportunity to find a sharp area as the knife dulls, so it can be used longer. Straight blades, as they become dull, don’t seem to bite the leather enough to get started with a cut. The disadvantage is you can’t just rub it back and forth like a standard straight edged knife when resharpening. Stropping takes a slight twist of the wrist, to keep parts of the cutting edge in contact with the strop throughout the stroke.

The rounded areas allow you to work into a skin, for headcaps and the spine. But the shape also allows you to use it like a standard English style knife for edge paring.

The third change is that the tip and heel of the cutting edge are rounded.  This prevents the knife from cutting through the skin when you are working away from the edge, similar to how a spokeshave blade works. In practice, I don’t miss having a pointed, sharp tip. A rounded tip also makes it less likely to dig into your paring surface.

The M2 Hybrid used like a standard English knife for edge paring.

All of these aspects combine to make a sensitive and versatile knife intended for professionals. An analogy for cyclists might be this is more like a track bike than a road bike. This knife, in addition to edge paring, can do most of what a spokeshave can do, albeit with more “workmanship of risk”. If you want the most versatile knife on the market, look no further.

Close up of a piece of goatskin feather pared,, so that the valleys of the grain are cut through. The middle of the blade was used for this, almost parallel to the edge of the leather..

Progressively paring towards the center. The rounded edges keep the blade from cutting through the leather as it stretches.

M2 Hybrid Paring knife. M2 Steel. The handle is hand carved wood, covered with vegetable tanned goatskin, and ergonomically shaped. The metal is .040″ thick, the handle around 5/8″ at the thickest point. It is about 1 inch wide and around 8-9″ in overall length. The secondary bevel is 13 degrees.  Hand sharpened to .1 micron.

The M2 Hybrid Paring Knife.  $250.00.  Order here.

Small M2 Hybrid knife. The best knife for onlays and intricate leather decorations. Also great for paring paper. M2 Steel. The metal is .025″ thick, about 5/8″ wide and 6-7″ long. Leather covered wood handle. The  secondary bevel is 13 degrees. Hand sharpened to .1 micron.

The Small M2 Hybrid Paring Knife.  $150.00.  Order here.

Small M2 Hybrid knife bottom left, regular size next to it.

An Overview of Leather Paring Knives, Tools and Machines

Many bookbinders, when getting into leather binding, are surprised by the wide variety of leather paring knives and machines. In bookbinding terminology there are four basic styles of knives and they are named for the nations that generally use them: English, French, German and Swiss. Other leather crafts use different terminologies.

In addition to paring knives, many binders use paring tools and machines. Most commonly a modified 151 style spokeshave, a double edge razor blade paring machine, or more rarely a razor blade plane. If you have a lot of work, skins can be sent out to be split. A few also thin leather by sanding or grinding. Below are my observations on the advantages and disadvantages of all of these.



1. English Style Knives (a straight blade, usually around 45 degrees relative to the length)

OLYMPUS DIGITAL CAMERA

In North America, most binders use an English Style knife for edge paring, followed by a spokeshave for making a long, gradual bevels. This type of beveling is used for English style fine bindings and rebacking. The knife making firm G. Barnsley made the most common knives used by English bookbinders in the 20th century.

ADVANAGES

DISADVANTAGES

  • Can only be used for edge paring
  • You will need a different style knife, a spokeshave, or a razor blade paring machine to thin larger areas



2. French or Swiss Style Knives (usually a slightly rounded blade, Swiss knives do not have a handle)

OLYMPUS DIGITAL CAMERA

French style knives are very popular with fine binders, many of whom were French trained. One defining stylistic feature is a center mounted wood handle, however. The handle on the French knives has always puzzled me, since you tend to hold it more on the blade and rest your palm on the handle. The handle protrudes onto the leather, limiting the angle the knife can be held. To get lower paring angle, I was the first to introduce the top mounted wood handle.

ADVANTAGES

  • One knife can do it all, though some binders use this in conjunction with an English style knife
  • Can be used with a scraping motion for thinning anywhere in a skin, useful for headcap or spine areas
  • Round blades seem to stay sharp longer, since there is at least some area that is still sharp enough to get a “bite” into the leather

DISADVANTAGES

  • Much more difficult to resharpen
  • More difficult to learn to use
  • More difficult to control
  • Scraping with a knife is more dangerous than spokeshaving or using a razor blade paring machine



3. German Style Knives

german-knife

Joseph Zaehnsdorf. The Art of Bookbinding. 2nd. ed. (London: George Bell and Sons, 1890), 91.

I’ve only used these a couple of times, so don’t really have an opinion. I did have a German trained student who used it expertly.  The one I have is slightly flexible. In  Zaehnsdorf’s 1890 The Art of Bookbinding, the German paring knife looks like a regular chef’s knife. Even the modern versions have a wedge shaped taper, so that the back is fairly thick and the opposite edge is sharp. Did the modern German style knife morph from a regular chef’s knife?



4. Modified 151 Spokeshave

spokeshave

A modified 151 style spokeshave is a powerful and effective tool for making long, gradual bevels in leather; ideal for rebacking or an English style full leather binding. It can also be used to bevel binders board. It is a lot of fun to use. These were originally intended for woodworkers, and I think binders started to modify these for leather starting in the 1920’s. Here is some of my research, and a tentative type study of 151 style spokeshaves.

ADVANTAGES

  • Much faster than a French knife for reducing leather thickness over a large area
  • Less chance of tearing through leather, especially with a shaving collector
  • A must for calf, which tears or gets marked in a razor blade paring machine

DISADVANTAGES

  • Difficult to modify a regular 151 style spokeshave
  • There is a bit of a learning curve to learn to use them
  • The leather must be clamped to the stone or glass, or the leather can be traditionally held with your stomach
  • Can’t be used with leather smaller than 6 inches or so in one direction, to allow for room for clamps and motion of the spokeshave



5. Razor Blade Leather Paring Machines: Scharffix, Bockman Paring Machine, and the forthcoming Felsted Skiver

screen-shot-2016-12-18-at-9-23-19-pm

Pre-Production Felsted Skiver. Photo: Malcolm Raggett, http://www.felstedskiver.com

Razor blade paring machines, including the Scharffix, Brockman and the new “Felsted Skiver” all use a very similar arrangement: a double edge razor blade suspended above an anvil or roller. These are very useful for thinning small or large areas flat. Razor blade machines excel at paring leather very thin. Common bookbinding applications include millimeter bindings, spines and corners for half bindings, and most commonly leather labels. A spokeshave is sometimes used to clean up ridges created from overlapping cuts on larger pieces.

My favorite paring machine is the original style Brockman, which is not available new anymore.  One advantage of his design is a curved bed for for the razor blade, which gives it significant rigidity and positions it to cut into the the leather straight on, rather than at an angle. Older hand held double edge razor blade handles also bend the blade like this. Brockman told me he made the first 100 of them himself, which are painted blue, and the later black ones were manufactured for him. A third green cast version was briefly produced in the 2000s (?), which looked very nice, but I haven’t tried it.

There are rigidity problems with many Scharffix machines, so make sure to test them out before purchase.

I’m looking forward to trying out the newest machine, the Felsted Skiver. Malcolm Raggett designed and is selling these. He has tested a variety of commercially available double edge razor blades, which is very useful research, and confirmed the Feather as one of the best blades.. But as I mentioned, I haven’t tried them out yet.

ADVANTAGES

  • Short learning curve
  • The best for paring very thin, flat areas of leather, like labels or half-leather bindings

DISADVANTAGES

  • Difficult to create bevels (at least for me)
  • Almost impossible to use on vegetable tanned calfskin
  • Blades wear out quickly and need to be replaced
  • Some of the machines can be tempermental
  • Changing the blade can alter the cutting depth



6. Razor Blade Planes

I wrote a brief history of them, then added some tips on their use, and later recorded my failed attempt to make a better version.  I ended up tearing a lot of leather, and went back to using a 151 modified spokeshave and razor blade paring machine. One skin can be as expensive as any of these tools.



7. Sending your Skin to a Specialist

This used to be common for french design binders, who even indicated what thickness the leather should be at various areas, through use of a template.  I’ve heard these specialists are disappearing, though. We do have leather manufactures who will split a skin (or more likely a dozen) down to a certain thickness. This is an excellent option if you are an edition binder. If the skin is thick enough you can get both sides back. The machine that does this is like a toothless horozontal bandsaw. I’ve used Hohenforst Splitting Company and they did an excellent job on a difficult leather: undyed and unfinished calfskin.



8. Sanding or Grinding

I wouldn’t recommend either of these methods unless there are extraordinary circumstances. Not only do these methods produce a lot of hazardous dust, they are very slow and, at least in my experience, grinding is very uncontrollable. I have done this if the leather is exceptionally weak, or need to level chatter that has resulted from an improperly tuned spokeshave. In this case choose a very coarse sandpaper, around 80 US grit. Sanding an entire piece of leather for rebacking or covering is very tedious.

Conclusion

After saying all of this, I think any knife made from good steel, properly hardened, that is hand sharpened, can work. I did some testing of tool steels and a summary is posted here. But I do think it is easiest to start with a hand sharpened knife, like the ones I sell in my store, in order to feel what sharp is, then learn to maintain this by stropping and eventually by resharpening.Happy paring!

The Straight Swiss Knife

The Straight Swiss Knife

There are two basic styles of leather paring knives used by bookbinders: an English style knife, with a straight blade positioned around 45 degrees to its length and a French or Swiss style knife with a curved blade positioned roughly 90 degrees to the length. I’ve combined some of the advantages of both of these styles into a new kind of knife — a straight Swiss knife.

For Swiss and French knife users, there are several advantages to a straight blade when compared to a rounded one. Straight blades are easier to sharpen and strop, can cut a straight line the width of the blade with a single downward slice (ie. for labels) and can be used for a final, smoothing cut to even out preliminary paring.  Current English knife users will appreciate some of the advantages of a Swiss style blade orientation. In use, the knife is very comfortable, since two fingers are used to push it, rather than relying just on the thumb.  An acute effective cutting angle is easy to attain, as illustrated below, because of the blade angle. Additionally, it is easy to pare in either direction, instead of flipping the  knife upside down and working on the bevel, which is more difficult to control.

The first pass when edge paring

The wedge shape of this knife is different than a standard Swiss shape, making it comfortable and easy to hold. The leather handle, located roughly at the midpoint of the knife, conforms to the natural shape of the hand when using the knife.  The width of the blade where is it held is 1.75 inches (45 mm) wide. The balance, shape, and weight of the knife give it a substantial presence in the hand.

In the image above, notice that my thumb and middle finger support the blade at the proper angle to the paring surface and pushes the knife forward. Notice that only one side of the blade is used and relatively small strips of leather removed at each pass.   Commonly three or four strips are pared off until the desired turn-in width and thickness is reached. It is very difficult to control cuts with the entire width of the blade unless you are using more of a smoothing cut pictured below, which is almost more of a scraping action — a bit like what a spokeshave does, except that your hands jig the blade.  For the spine area and general scraping, however, a rounded blade is still preferable, since only a small part of the blade is actually cutting at any one time. The relatively wide blade makes it easy to reduce the thickness of a corner with one sweeping slice, which helps make a neat corner.

A smoothing, finishing cut using entire width of the blade

SPECIFICATIONS: A2 cryogenically quenched steel, HRC 62. Length: 6.75 inches (171mm).  Width: 1.875 inches (48mm) at cutting edge, tapering to 1.375 inches (35 mm). Thickness: .094 inches (2.4mm). Weight: about 5 oz (142 g). Bevel: 13 degrees. Leather handle. Horsebutt blade cover. Fully sharpened, ready to use.

PRICE:  $125.00



A Knife From The Hood

birck-ft

birck

At first, I thought the above knife was a German style paring knife, but now I’m not so sure. German knives are almost always somewhat flexiable, and this one is very rigid.   Notice the small recess on the handle, near the blade, perhaps worn by fingers gripping the handle over the decades.  Even a light surface cleaning could destroy not only important use evidence, but the overall beauty of the knife.  As I have said before, the over-cleaning and “restoration” of  hand tools is perhaps the most significant ongoing loss of cultural property  that commonly occurs.   The blade is full tang and has a gradual taper in thickness towards the cutting edge. Judging from the scratch patterns in the top picture, the owner must have had a stressful encounter with his grinding wheel!  But I find these marks interesting evidence of the history of the tool, as well as a visually refreshing antidote to the ubiquitous monotony of the highly regulated machine grind marks found on new tools.  The handle is an unidentified light colored wood that has been stained and is still firmly attached to the tang. The edges of the handle is still quite sharp, and the various ways I have tried to hold it all are somewhat uncomfortable.

Matt Murphy  found some information about Fred J. Birck:  “From 1903-04 he worked at 93 Essex St. In 1905-06, Fred. J. Birck is listed as being a part of Birck & Zamminer Cutlery, which is located at 154 Essex St.  In 1908-1912, Birck is listed at two seperate addresses, 132 Essex St. and 17 Cooper Sq. East. In 1912-1913, the primary address is changed to 17 Cooper Sq. E.  In 1913-1914, the partnership must have been dissolved, because only Birck is listed, and the only address is 17 Cooper Sq. E. until 1925.  Also, Mr. Birck made his home in Jersey City, New Jersey, as his address is often listed as 144 Hutton St. (Which still stands to this day.)”

So the knife is possibly from 1913-25.  Aside from the beautiful, insanely deep makers mark, I was attracted to the fact that another knife-maker worked in the East Village of NYC, only about 5 blocks from where my studio is now. There is even an old bar,  McSorley’s, established in 1854, still operating right around the corner from Birck’s 17 Cooper Sq. address. Perhaps Birck had a drink there.  I’ll raise a glass to him next time I’m there.



Don Rash posted a similar looking knife on his blog, unfortunately no makers mark.  I looked through Salaman’s Dictionary of Leather-working Tools c. 1700-1950 and couldn’t find any similar knives, and Salaman covers some pretty obscure leather-working trades ( ie. gut string maker, hydraulic pump-leather maker) but tends contain more English rather than American references.



Below is the German knife from Zaehnsdorf’s The Art of Bookbinding, 6th Ed. 1903. It almost looks like the knife is shaded more heavily on the top edge, to make clear the blade tapers toward the other edge?

german-paring-knife
