The Scratches Don’t Lie and The Big Board: Impressions from Teaching in the Netherlands.

Earlier this summer, I spent a couple of throughly enjoyable weeks in the Netherlands, teaching two workshops through the auspices of Restauratoren Nederland, at the beautiful bindery of Wytze Fopma in Friesland. First there was a 3-day sharpening/ spokeshave modification class, a wadlopen and tour of Mennonite sites, then a 5-day 18th c. French binding class. It was all very, very good.

Each time I teach, I keep adding current research. I’ve taught versions of the sharpening class over thirty times, and the French at least a dozen. It sounds cliche, but I do learn something new each time.

This class, Constant Lem, book conservator at Koninklijke Bibliotheek, convinced me of the importance of the 180 degree shoulder that the French bindings often have.  I’d considered and worked on this, however working together we made progress on this historically unique(?) structural feature.

photo-35

The steel folder, which Ben Elbel calls “score!”.

Before the workshop, I visited Ben Elbel, of Elbel Libro, in Amsterdam. He has a large studio, is doing some very nice work, and has a board beveling machine that I plan to steal at some point. Ben gave me a nifty steel folder which he sells. It is a nice size for detailed work, fitting comfortably in the hand, well made, and is also useful for blind lines. It comes in an attractive die cut storage folder. Metal folders keep popping up every now and then in the history of bookbinding: the earliest I’ve seen was patented in 1889.

Below are images from the workshop.

weir7

Examining a spokeshave blade while sharpening.  Photo copyright Anke van der Schaaf, 2015. All rights reserved. http://www.fopmawier.nl

One of the most important aspects in freehand sharpening involves looking at reflections and scratch patterns in the blade, in order to understand what you are doing and what needs to be done. The visual feedback lets you know how to alter your hand pressure or technique. The scratches don’t lie.



weir2

Tallying up The Big Board.  Photo copyright Anke van der Schaaf, 2015. All rights reserved. http://www.fopmawier.nl

The Big Board is a learning tool I use in the French class to keep track of questions, deviations from historic practice, instructor mistakes, material differences, etc.  Whoever has the most observations wins a prize, in this case a small lifting knife. Often there are over 150 observations. This helps keep us aware of inaccuracies generalized from our modern craft training that can creep into the historic style we are trying to understand.

As invasive treatments continue to become more infrequent in book conservation, the type of knowledge gained from making historic models will help keep book conservators relevant (I hope!), by increasing our knowledge of how these books were originally made.  Conservation as interpretation?



weir4

Beating a textblock before sewing. Photo copyright Anke van der Schaaf, 2015. All rights reserved. http://www.fopmawier.nl

Not only did we have a custom made beating hammer, but we borrowed an anvil from the Blacksmith. A wonderfully solid substitute for a beating stone!



weir5

Wytze’s large standing press. He said it took nine people to tilt it back upright after it was brought in through the door. A huge blocking press is on the left.  Come to think of it, EVERYTHING in the bindery was super heavy duty. My photo.

Wytze has the most massive operational standing press I’ve ever seen. He mentioned that it is the largest in Holland. He is operating the worm drive. Once the center screw is tightened as much as possible, to generate even more pressure, the drive can crank the main press screw another turn or so. The drive can be easily disengaged to quickly raise or lower the press. As a demonstration, he pressed some of our textblock paper so hard it sunk into the MDF pressing boards, creating a clamshell. It had little to do with the class, but was too impressive not to mention.



DSC00341

Some of the class at work. Photo copyright Natasha Herman. http://www.redbonebindery.com



weir1

The finished books. Photo copyright Anke van der Schaaf, 2015. All rights reserved. http://www.fopmawier.nl

On the left is an 18th century skull the Wytze found, the finished books, an 18th century (?) French (Dutch?) beating hammer on the right, and in the back, the printed handouts for the workshop bound en-broche by Wytze and Herre. We started with the same tan calfskin; the color variations on the finished books resulted from varying applications of glair, paste wash, and warm burnishing. These are powerful and inert ways to control the color and surface sheen of leather without dyeing.

The skull and beating hammer literally and symbolically bookend this workshop: we were working with the head and the hand, using theory and praxis, to learn more about the nature of 18th c. French binding.





7 thoughts on “The Scratches Don’t Lie and The Big Board: Impressions from Teaching in the Netherlands.

  1. Peter Verheyen

    “Importance of the 180 degree shoulder that the French bindings often have.”

    180 degree shoulder = no shoulder or backed on itself?

    Intrigued…

  2. Jeff Peachey Post author

    These books are often backed so that the endsheet is adhered 2-3mm on the exterior face of the boards. At first I though it was an accident, but many, many books have this. I coined the term “180 degree shoulder” but am open to suggestions for something better. Thoughts?

  3. chelame

    Hey Jeff,

    So great to hear about your observations and teaching experiences. Thanks!

    Just out of curiosity, any sign of spine straps on books at the Mennonite sites?

    Doesn’t the “180 “shoulder come naturally if you pound the heck out of the shoulder with a hammer after lacing on the boards? It does make for a smooth, gap free transition between text and board …

  4. Jeff Peachey Post author

    I didn’t get a chance to see a lot of Mennonite books, just a couple of Martyr’s Mirrors, and they had plain spines, though one had a chammois second covering before it was restored.

    With the French books, at least as Dudin described it, we laced on the boards before backing, when coupled with the small backing boards (visually described by Dudin and Diderot) , and the multiple books backed at the same time, it was difficult to get the shoulder large enough. And the 2-on sewing, which I have always seen…. Anyway, it seems to create a small area where the leather is not adhered near the spine on the outside of the board, which lets the leather flex a little more easily. Also, some books have a larger shoulder but are only backed to 90 or so, so that it is proud of the boards, again which might help opening, somewhat along the lines of an English style case binding. I’d love to know when these started, BTW>

  5. bhbeidler

    That Big Board is a genius idea – what a great way to keep track of a workshop, the deviations from historic practice in particular. Love that!
